Fiber laser marking machine is suitable for most metal materials, such as gold, silver, copper, alloy, aluminum, steel, stainless steel and some non-metal materials, such as plastics (engineering plastics and hard plastics, etc.) electroplating materials, coating materials, spraying materials, plastic rubber, epoxy resin, ceramics, etc.
Email: joy@dumanlaser.com
Item NO. :
DMF-20Payment :
L/C D/A D/P T/T Western UnionProduct Origin :
ChinaShipping Port :
XiamenLead Time :
15 daysPortable Fiber Laser Engraving Machine for Metal Materials Marking
This big size cross sliding laser marker uses cross slide technology, large-format splicing can be realized through the movement of the worktable, and high-precision large-format marking can be performed. With the auto-focus function, it can perform one-time marking processing on materials of different heights, eliminating the need for repeated alignment and marking processes and saving a lot of time.
Fiber laser marking machine is suitable for most metal materials, such as gold, silver, copper, alloy, aluminum, steel, stainless steel and some non-metal materials, such as plastics (engineering plastics and hard plastics, etc.) electroplating materials, coating materials, spraying materials, plastic rubber, epoxy resin, ceramics, etc.
It is widely used in electronic components, integrated circuits (IC), electrical circuits, mobile communications, hardware products, kitchen utensils, precision instruments, glasses and clocks, computer keyboards, jewelry, auto parts, plastic buttons, plumbing accessories, sanitary ware, PVC pipes, medical equipment, packaging bottles and other industries
Features:
1: Long use time, more than 100,000 hours.
2: Compact laser source with air cooling.
3: The efficiency of traditional laser marking machine or laser engraving machine is increased by 2 to 5 times.
4: Ultra-high quality galvanometer scanning system.
5: Get accurate markings with high accuracy and repeatability every time you use the galvo scanner and electronic controls.
6: The performance is more stable.
7: Control board and marking software. The software control system has a window interface, including files output by Coreldraw, AutoCAD, Photoshop and other software. It can support various file formats such as PLT, DXF, PCX, BMP, etc.
8: The output power is stable, the light pattern is good, and the beam quality is excellent.
9: Marking speed is fast and high precision.
10: Exquisite appearance, simple and convenient.
Technical parameter
|
Item / Model |
DMF-20(Optional:30/50/60/70/100/120/150W) |
|
Laser source |
MAX(Optional:Germany IPG/China CAS/RAYCUS/JPT Mopa color marking) |
|
Laser power |
20w, 30w, 50w,60w ,70w,100,120w,150w |
|
Laser type |
Fiber laser |
|
Graphic Format Supported |
DXF,PLT,BMP,JPG,PNG,TIP,PCX,TGA,ICO, |
|
Marking speed |
≤8000mm/S |
|
Max.Marking Depth |
≤0.4mm |
|
Laser Wavelength |
1064nm |
|
Marking lines |
0.06-0.1mm |
|
Minimum line width |
0.06mm |
|
Minimum character |
0.15mm |
|
Resolution ratio |
0.01mm |
|
Graphic format supported |
BMP, PLT, DST, DXF, AI |
|
Software supported |
TAJIMA, CorelDraw, Photoshop, AutoCAD |
|
Equipment Dimensions |
920*830*1160mm(different model has different size,detailed can be confirmed with sellers) |
|
Net Weight: |
35kg(different configuration has small difference) |
|
Unit Power |
≤500W |
|
Optional Spare Parts |
Rotary/Protection glasses/outside red light/night light and other optional customized parts and so on. |
Samples
Fiber laser marking machine is suitable for most metal materials, such as gold, silver, copper, alloy, aluminum, steel, stainless steel and some non-metal materials, such as plastics (engineering plastics and hard plastics, etc.) electroplating materials, coating materials, spraying materials, plastic rubber, epoxy resin, ceramics, etc. Email: joy@dumanlaser.com
Fiber laser marking machine is suitable for most metal materials, such as gold, silver, copper, alloy, aluminum, steel, stainless steel and some non-metal materials, such as plastics (engineering plastics and hard plastics, etc.) electroplating materials, coating materials, spraying materials, plastic rubber, epoxy resin, ceramics, etc. Email: joy@dumanlaser.com
Fiber laser marking machine is suitable for most metal materials, such as gold, silver, copper, alloy, aluminum, steel, stainless steel and some non-metal materials, such as plastics (engineering plastics and hard plastics, etc.) electroplating materials, coating materials, spraying materials, plastic rubber, epoxy resin, ceramics, etc. Email: joy@dumanlaser.com
Fiber laser marking machine is suitable for most metal materials, such as gold, silver, copper, alloy, aluminum, steel, stainless steel and some non-metal materials, such as plastics (engineering plastics and hard plastics, etc.) electroplating materials, coating materials, spraying materials, plastic rubber, epoxy resin, ceramics, etc. Email: joy@dumanlaser.com
Fiber laser marking machine is suitable for most metal materials, such as gold, silver, copper, alloy, aluminum, steel, stainless steel and some non-metal materials, such as plastics (engineering plastics and hard plastics, etc.) electroplating materials, coating materials, spraying materials, plastic rubber, epoxy resin, ceramics, etc. Email: joy@dumanlaser.com
Fiber laser marking machine is suitable for most metal materials, such as gold, silver, copper, alloy, aluminum, steel, stainless steel and some non-metal materials, such as plastics (engineering plastics and hard plastics, etc.) electroplating materials, coating materials, spraying materials, plastic rubber, epoxy resin, ceramics, etc. Email: joy@dumanlaser.com
It is suitable for special-shaped surface marking, high and low-level surface marking, embossing, cleaning, surface treatment. Email: joy@dumanlaser.com
CX series laser marking machine is used in electronic components, hardware products, tool accessories, integrated circuits (IC), electrical appliances, mobile communications, precision instruments, glasses and clocks, jewelry, auto parts, plastic buttons, PVC pipes, medical equipment and other industries. Please send your inquiry to Email: joy@dumanlaser.com
