The laser roughen technology is to preheat and strengthen the roll surface by using a high-energy, high repetition rate pulsed laser beam after focusing the negative defocusing light, and form a micro molten pool when the focused focus hits the roll surface.
Please send your inquiry to Email: joy@dumanlaser.com
Item NO. :
DMR-500Payment :
L/C D/A D/P T/T Western UnionProduct Origin :
ChinaShipping Port :
XiamenLead Time :
15 daysMobile Handheld Laser Roughen Equipment
The laser texturing machine uses hand-held optical fiber to replace the fixed optical path, which is flexible and convenient. It overcomes the limitation of the workspace, can realize the texturing of various metal surfaces, and can replace sand blasting texturing or shot blasting texturing. It is a new generation of texturing technology.
Advantages
1. The disorderedroughen process is mature: each laserroughen point can be disordered through the core pulse string laser output, and theroughen effect can be developed according to different Ra/RPc values in combination with theroughen process.
2. High processing efficiency: the pulse frequency of laserroughen equipment is up to 100kHz, and its processing efficiency is far higher than that of traditional acousto-optic modulation YAG laserroughen equipment, which can meet the production requirements of the factory.
3. High adjustable range of roughness: under the condition of high efficiency processing, the laser power can be directly controlled to change the roughness parameters, and the Ra value of 0.5~20 can be * * high μ M is adjustable.
4. High uniformity of roughness: laserroughen equipment is a laserroughen equipment that can realize the integration of laser and machine tool in the world up to now, completely solving the problem of deviation of roller surface roughness caused by the original equipment flight light path.
5. Good safety: based on the consideration of equipment safety, a stable heavy-duty lathe and roll bracket are configured, and electronic induction anti-collision system and laser safety logic control system are used.
6. Small floor space: The laserroughen equipment realizes the integration of laser and machine tool, thus greatly reducing the area occupied by the equipment.
7. Low operating costs: Compared with electric sparkroughen equipment and shot peeningroughen equipment, laserroughen equipment has lower operating costs.
8. High degree of automation: the international leading numerical control system is adopted, with the function of "one keyroughen". The equipment is easy to operate and has high processing accuracy.
9. Good stability: the equipment integrates laser and machine tool, and uses international * * advanced fiber laser technology, so the stability of the equipment is very high.
10. Low environmental requirements: after years of accumulation, self protection of equipment in different use environments has been accumulated, which can be used in relatively harsh environments.
11. Simple maintenance: the equipment is highly integrated, stable and easy to maintain.
Specificaiton
|
Equipments date |
Laser roughen system |
||
|
Equipment model |
RM-0100 |
RM-0300 |
RM-0500 |
|
Wave length |
1064nm |
||
|
Average power |
100W |
300W |
500W |
|
Power adjust |
10%-100% |
||
|
Laser type |
fibre-detector coupling |
||
|
Laser life |
50,000-60,000 hours |
||
|
Laser class |
IIII level |
||
|
Cable length |
3/5 meters optical fiber |
||
|
Laser transmission |
Scanner Lenses |
||
|
Texturing roughness |
0.5-100 um |
||
|
Texturing size |
50-120 um |
||
|
Software system |
human-computer interface |
||
|
Environmental temp |
5-40 ℃ |
||
|
Environmental humidity |
10-95 % |
||
|
Cooling method |
Air cooling |
Water cooling |
|
|
Equipment voltage |
220V+- 10% |
||
|
Equipment capacity |
1000W |
3000W |
5000W |
|
Equipment weight |
140 KG |
240KG |
320KG |
